Material options |
1. 304 STAINLESS STEEL 0.3mm or 0.4mm 2. Aluminum material door panel with polyethene foam filled 3. Galvanized steel plate, with any ral color |
Door panel height |
450mm & 550mm |
Normal Color |
Porcelain white, light gray,coffee color and stainless steel color, or any Ral color. |
Rail & Fitting |
Hot dip galvanized steel rail and galvanized bracket & hinges. Aluminum powder coated 2.8mm thick rail is also optional. |
Sealing |
With full sealed, weather resistance & well protection & soundproof. |
Control |
Automatic & remote controlled. Power rate: 110V/220V/380V |
Feature for door motorized system |
Route memorable, door self locking when power cut off, self-checking up, non hand nipping, safety operation. |
MODEL |
600N |
800N |
1000N |
1200N |
|||
Voltage range/rated frequency |
220~240V AC, 50/60HZ |
||||||
Rated power |
200W |
235W |
245W |
260W |
|||
Maximum lifting force |
600N |
800N |
1000N |
1200N |
|||
Door opening speed |
180mm/s |
||||||
Lamp type |
LED |
||||||
Lighting time |
3 minutes |
||||||
Coding type |
Rolling code |
||||||
Radio frequency |
433.92 MHZ or other requirements |
||||||
Ambient temperature |
-20°C~+40°C |
||||||
Relative humidity |
<90% |
||||||
Applicable door area |
10m² |
12m² |
14m² |
16m² |
|||
